NETGEAR M4100 Series ProSAFE

Switching Commands
92
M4100 Series ProSAFE Managed Switches
The show dot1x detail <slot/port> command displays the following MAC-based
dot1x fields if the port-control mode for that specific port is MAC-based. For each client
authenticated on the port, the show dot1x detail <slot/port> command displays the
following MAC-based dot1x parameters if the port-control mode for that specific port is
MAC-based.
If you use the optional parameter statistics <slot/port>, the following dot1x statistics
for the specified port appear.
Term Definition
Supplicant
MAC-Address
The MAC-address of the supplicant.
Authenticator
PAE State
Current state of the authenticator PAE state machine. Possible values are Initialize,
Disconnected, Connecting, Authenticating, Authenticated, Aborting, Held,
ForceAuthorized, and ForceUnauthorized.
Backend
Authentication
State
Current state of the backend authentication state machine. Possible values are Request,
Response, Success, Fail, Timeout, Idle, and Initialize.
VLAN-Assigned The VLAN assigned to the client by the radius server.
Logical Port The logical port number associated with the client.
Term Definition
Port The interface whose statistics are displayed.
EAPOL Frames
Received
The number of valid EAPOL frames of any type that have been received by this
authenticator.
EAPOL Frames
Transmitted
The number of EAPOL frames of any type that have been transmitted by this
authenticator.
EAPOL Start
Frames
Received
The number of EAPOL start frames that have been received by this authenticator.
EAPOL Logoff
Frames
Received
The number of EAPOL logoff frames that have been received by this authenticator.
Last EAPOL
Frame Version
The protocol version number carried in the most recently received EAPOL frame.
Last EAPOL
Frame Source
The source MAC address carried in the most recently received EAPOL frame.
EAP
Response/Id
Frames
Received
The number of EAP response/identity frames that have been received by this
authenticator.
