B1.29 AArch32 GIC system registers
The following table shows the GIC system registers in AArch32 state.
See the Arm
®
Generic Interrupt Controller Architecture Specification, GIC architecture version 3.0 and
version 4.0 for more information.
Table B1-28 AArch32 GIC system registers
Name CRn Op1 CRm Op2 Type Reset Width Description
ICC_SGI1R - 0 c12 - WO - 64-bit SGI Generation Register 1
ICC_ASGI1R - 1 c12 - WO - 64-bit Alternate SGI Generation Register 1
ICC_SGI0R - 2 c12 - WO - 64-bit SGI Generation Register 0
ICC_PMR c4 0 c6 0 RW
0x00000000
32-bit Priority Mask Register
ICC_IAR0 c12 0 c8 0 RO - 32-bit Interrupt Acknowledge Register 0
ICC_EOIR0 1 WO - 32-bit End Of Interrupt Register 0
ICC_HPPIR0 2 RO - 32-bit Highest Priority Pending Interrupt Register 0
ICC_BPR0 3 RW
0x00000002
32-bit Binary Point Register 0
ICC_AP0R0 4 RW
0x00000000
32-bit Active Priorities 0 Register 0
ICC_AP1R0 c9 0 RW
0x00000000
32-bit Active Priorities 1 Register 0
ICC_DIR c11 1 WO - 32-bit Deactivate Interrupt Register
ICC_RPR 3 RO - 32-bit Running Priority Register
ICC_IAR1 c12 0 RO - 32-bit Interrupt Acknowledge Register 1
ICC_EOIR1 1 WO - 32-bit End Of Interrupt Register 1
ICC_HPPIR1 2 RO - 32-bit Highest Priority Pending Interrupt Register 1
ICC_BPR1 3 RW
0x00000003
32-bit
Binary Point Register 1
This is the reset value in non-secure state. In secure
state, the reset value is 0x00000002.
ICC_CTLR 4 RW
0x00000400
32-bit Interrupt Control Register
ICC_SRE 5 RW
0x00000000
32-bit System Register Enable Register
ICC_IGRPEN0 6 RW
0x00000000
32-bit Interrupt Group Enable Register 0
ICC_IGRPEN1 7 RW
0x00000000
32-bit Interrupt Group Enable Register 1
ICH_AP0R0 4 c8 0 RW
0x00000000
32-bit Interrupt Controller Hyp Active Priorities Register (0,0)
ICH_AP1R0 c9 0 RW
0x00000000
32-bit Interrupt Controller Hyp Active Priorities Register (1,0)
ICC_HSRE 5 RW
0x00000000
32-bit System Register Enable Register for EL2
ICH_HCR c11 0 RW
0x00000000
32-bit Interrupt Controller Hyp Control Register
ICH_VTR 1 RO
0x90080003
32-bit Interrupt Controller VGIC Type Register
ICH_MISR 2 RO
0x00000000
32-bit Interrupt Controller Maintenance Interrupt State
Register
B1 AArch32 system registers
B1.29 AArch32 GIC system registers
