C11.1 ETM register summary
This section summarizes the ETM trace unit registers.
All ETM trace unit registers are 32 bits wide. The description of each register includes its offset from a
base address. The base address is defined by the system integrator when placing the ETM trace unit in
the Debug-APB memory map.
Table C11-1 ETM trace unit register summary
Name Type Description
TRCPRGCTLR RW
C11.2 Programming Control Register on page C11-736
TRCSTATR RO C11.3 Status Register on page C11-737
TRCCONFIGR RW C11.4 Trace Configuration Register on page C11-738
TRCAUXCTLR RW C11.6 Auxiliary Control Register on page C11-741
TRCEVENTCTL0R RW C11.7 Event Control 0 Register on page C11-743
TRCEVENTCTL1R RW C11.8 Event Control 1 Register on page C11-745
TRCSTALLCTLR RW C11.9 Stall Control Register on page C11-746
TRCTSCTLR RW C11.10 Global Timestamp Control Register on page C11-747
TRCSYNCPR RW C11.11 Synchronization Period Register on page C11-748
TRCCCCTLR RW C11.12 Cycle Count Control Register on page C11-749
TRCBBCTLR RW C11.5 Branch Broadcast Control Register on page C11-740
TRCTRACEIDR RW C11.13 Trace ID Register on page C11-750
TRCVICTLR RW C11.14 ViewInst Main Control Register on page C11-751
TRCVIIECTLR RW C11.15 ViewInst Include-Exclude Control Register on page C11-753
TRCVISSCTLR RW C11.16 ViewInst Start-Stop Control Register on page C11-754
TRCSEQEVR0 RW C11.17 Sequencer State Transition Control Registers 0-2 on page C11-755
TRCSEQEVR1 RW C11.17 Sequencer State Transition Control Registers 0-2 on page C11-755
TRCSEQEVR2 RW C11.17 Sequencer State Transition Control Registers 0-2 on page C11-755
TRCSEQRSTEVR RW C11.18 Sequencer Reset Control Register on page C11-757
TRCSEQSTR RW C11.19 Sequencer State Register on page C11-758
TRCEXTINSELR RW C11.20 External Input Select Register on page C11-759
TRCCNTRLDVR0 RW C11.21 Counter Reload Value Registers 0-1 on page C11-760
TRCCNTRLDVR1 RW C11.21 Counter Reload Value Registers 0-1 on page C11-760
TRCCNTCTLR0 RW C11.22 Counter Control Register 0 on page C11-761
TRCCNTCTLR1 RW C11.23 Counter Control Register 1 on page C11-763
TRCCNTVR0 RW C11.24 Counter Value Registers 0-1 on page C11-765
TRCCNTVR1 RW C11.24 Counter Value Registers 0-1 on page C11-765
TRCIDR8 RO C11.25 ID Register 8 on page C11-766
TRCIDR9 RO C11.26 ID Register 9 on page C11-767
C11 ETM registers
C11.1 ETM register summary
