C5.2 Encoding for tag and data in the L1 instruction cache
The following table shows the format of the Instruction Cache Tag Read Operation Register and the
Instruction Cache Data Read Operation Register.
The set-index range parameter (S) is determined by the following formula:
S = log
2
(size of the instruction cache in bytes / 2)
Table C5-3 Instruction cache tag and data location encoding
Bit field Description
[31] Cache Way
[30:S] Unused
[S-1:6] Set index
[5:2] Line offset
[1:0] Unused
The following table shows the format of the information in Data Register 0 following an Instruction
Cache Tag Read Operation.
Table C5-4 Instruction cache tag data format
Bits Description
[31] Unused.
[30:29]
Valid and set mode:
0b00
A32.
0b01
T32.
0b10
A64.
0b11
Invalid.
[28] Non-secure state (NS).
[27:0] Tag address.
The Instruction Cache Data Read Operation returns two entries from the cache in Data Register 0 and
Data Register 1 corresponding to the 16-bit aligned offset in the cache line:
Data Register 0 Bits[19:0] data from cache offset+ 0b00.
Data Register 1 Bits[19:0] data from cache offset+ 0b10.
In A32 or A64 state these two fields combined always represent a single predecoded instruction. In T32
state, they can represent any combination of 16-bit and partial or full 32-bit instructions.
