ARM Cortex-A35 User Manual

C11.25 ID Register 8
The TRCIDR8 characteristics are:
Purpose
Returns the maximum speculation depth of the instruction trace stream.
Usage constraints
There are no usage constraints.
Configurations
Available in all configurations.
Attributes
See C11.1 ETM register summary on page C11-733.
31
0
MAXSPEC
Figure C11-24 TRCIDR8 bit assignments
MAXSPEC, [31:0]
The maximum number of P0 elements in the trace stream that can be speculative at any time.
0 Maximum speculation depth of the instruction trace stream.
The TRCIDR8 can be accessed through the external debug interface, offset 0x180.
C11 ETM registers
C11.25 ID Register 8
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C11-766
Non-Confidential
