B1.47 Domain Access Control Register
The DACR characteristics are:
Purpose
Defines the access permission for each of the sixteen memory domains.
Usage constraints
This register is accessible as follows:
EL0
(NS)
EL0
(S)
EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
- - RW RW RW RW RW
Configurations
DACR (NS) is architecturally mapped to AArch64 register DACR32_EL2. See B2.39 Domain
Access Control Register, EL2 on page B2-421.
If EL3 is using AArch32, there are separate Secure and Non-secure instances of this register.
If EL3 is using AArch32, write access to DACR(S) is disabled when the CP15SDISABLE2
signal is asserted HIGH.
DACR has no function when TTBCR.EAE is set to 1 to select the Long-descriptor translation
table format.
Attributes
DACR is a 32-bit register.
31
30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
0
D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0
Figure B1-11 DACR bit assignments
D<n>, bits [2n+1:2n], for n = 0 to 15, [31:0]
Domain n access permission, where n = 0 to 15. Permitted values are:
0b00 No access. Any access to the domain generates a Domain fault.
0b01 Client. Accesses are checked against the permission bits in the translation tables.
0b11 Manager. Accesses are not checked against the permission bits in the translation tables.
The value 0b10 is reserved.
To access the DACR:
MRC p15, 0, <Rt>, c3, c0, 0 ; Read DACR into Rt
MCR p15, 0, <Rt>, c3, c0, 0 ; Write Rt to DACR
Register access is encoded as follows:
Table B1-41 DACR access encoding
coproc opc1 CRn CRm opc2
1111 000 0011 0000 000
B1 AArch32 system registers
B1.47 Domain Access Control Register
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B1-221
Non-Confidential
