C12.2 External register access permissions to the CTI registers
External access permission to the cross trigger registers is subject to the conditions at the time of the
access.
The following table describes the processor response to accesses through the external debug and
memory-mapped interfaces.
Table C12-2 External register conditions
Name Condition Description
Off EDPRSR.PU is 0
Processor power domain is completely off, or in a low-power state where the
processor power domain registers cannot be accessed.
DLK EDPRSR.DLK is 1 OS Double Lock is locked.
OSLK OSLSR_EL1.OSLK is 1 OS Lock is locked.
EDAD
AllowExternalDebugAccess() ==FALSE
External debug access is disabled. When an error is returned because of an
EDAD condition code, and this is the highest priority error condition,
EDPRSR.SDAD is set to 1. Otherwise EDPRSR.SDAD is unchanged.
SLK Memory-mapped interface only Software lock is locked. For the external debug interface, ignore this row.
Default - None of the conditions apply, normal access.
The following table shows an example of external register condition codes for access to a cross trigger
register. To determine the access permission for the register, scan the columns from left to right. Stop at
the first column a condition is true, the entry gives the access permission of the register and scanning
stops.
Table C12-3 External register condition code example
Off DLK OSLK EDAD SLK Default
- - - - RO/WI RO
C12 CTI registers
C12.2 External register access permissions to the CTI registers
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C12-828
Non-Confidential
