C12.9 CTI Peripheral Identification Register 3
The CTIPIDR3 characteristics are:
Purpose
Provides information to identify a CTI component.
Usage constraints
The accessibility of CTIPIDR3 by condition code is:
Off DLK OSLK EPMAD SLK Default
- - - - RO RO
C12.2 External register access permissions to the CTI registers on page C12-828 describes the
condition codes.
Configurations
CTIPIDR3 is in the Debug power domain.
CTIPIDR3 is optional to implement in the external register interface.
Attributes
See the register summary in C12.1 Cross trigger register summary on page C12-826.
RES0
31 0
34
CMOD
78
REVAND
Figure C12-6 CTIPIDR3 bit assignments
[31:8]
Reserved, RES0.
REVAND, [7:4]
0x0 Part minor revision.
CMOD, [3:0]
0x0 Customer modified.
CTIPIDR3 can be accessed through the external debug interface, offset 0xFEC.
C12 CTI registers
C12.9 CTI Peripheral Identification Register 3
