A3.3 Resets
The CortexA35 processor has active-LOW reset input signals that can be asynchronously asserted
HIGH to LOW, or deasserted LOW to HIGH.
nCPUPORESET[CN:0]
Where CN is the number of cores minus one.
Power On reset signals. These primary, cold reset signals initialize all resettable registers in the
corresponding core, including debug registers and ETM registers.
nCORERESET[CN:0]
These primary reset signals initialize all resettable registers in the corresponding core, not
including debug registers and ETM registers.
nPRESETDBG
This single, processor-wide signal resets the integrated CoreSight components that connect to
the external PCLK domain, such as debug logic.
nL2RESET
This single, processor-wide signal resets all resettable registers in the L2 memory system and
the logic in the SCU or mini-SCU.
nMBISTRESET
An external MBIST controller can use this signal to reset the entire SoC. The nMBISTRESET
signal resets all resettable registers in the cluster, for entry into, and exit from, MBIST mode.
Reset synchronization logic inside the processor ensures that reset deassertion is synchronous for all
resettable registers. The processor clock is not required for reset assertion, but it must be present for reset
deassertion to ensure reset synchronization.
In general, the reset time only requires three processor clock cycles.
Note
The application of a retention state can affect how long reset assertion is required. You must hold the
reset signal active-LOW until the power returns and the unit or processor is ready for the reset to take
effect if:
The Advanced SIMD and floating-point unit of a core undergoing a reset is in retention state.
A core that is being reset is in retention state.
The time that is taken for retention exit and the behavior of the power controller varies by partner and by
implementation.
The following table describes the valid reset signal combinations. All other combinations of reset signals
are illegal. In the table, n designates the core that is reset.
A3 Clocks, Resets, and Input Synchronization
A3.3 Resets
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
A3-52
Non-Confidential
