ARM Cortex-A35 User Manual

C12.1 Cross trigger register summary
This section describes the cross trigger registers in the Cortex‑A35 processor. These registers are
accessed through the external debug interface.
The following table gives a summary of the Cortex‑A35 cross trigger registers. For those registers not
described in this chapter, see the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture
profile.
Table C12-1 Cross trigger register summary
Offset Name Type Description
0x000
CTICONTROL RW CTI Control Register
0x000-0x00C
- - Reserved
0x010
CTIINTACK WO CTI Output Trigger Acknowledge Register
0x014
CTIAPPSET RW CTI Application Trigger Set Register
0x018
CTIAPPCLEAR WO CTI Application Trigger Clear Register
0x01C
CTIAPPPULSE WO CTI Application Pulse Register
0x020
CTIINEN0 RW CTI Input Trigger to Output Channel Enable Registers
0x024
CTIINEN1 RW
0x028
CTIINEN2 RW
0x02C
CTIINEN3 RW
0x030
CTIINEN4 RW
0x034
CTIINEN5 RW
0x038
CTIINEN6 RW
0x03C
CTIINEN7 RW
0x040-0x09C
- - Reserved
0x0A0
CTIOUTEN0 RW CTI Input Channel to Output Trigger Enable Registers
0x0A4
CTIOUTEN1 RW
0x0A8
CTIOUTEN2 RW
0x0AC
CTIOUTEN3 RW
0x0B0
CTIOUTEN4 RW
0x0B4
CTIOUTEN5 RW
0x0B8
CTIOUTEN6 RW
0x0BC
CTIOUTEN7 RW
0x0C0-0x12C
- - Reserved
0x130
CTITRIGINSTATUS RO CTI Trigger In Status Register
0x134
CTITRIGOUTSTATUS RO CTI Trigger Out Status Register
0x138
CTICHINSTATUS RO CTI Channel In Status Register
0x13C
CTICHOUTSTATUS RO CTI Channel Out Status Register
0x140
CTIGATE RW CTI Channel Gate Enable Register
C12 CTI registers
C12.1 Cross trigger register summary
