C10.16 Performance Monitors Peripheral Identification Register 4
The PMPIDR4 characteristics are:
Purpose
Provides information to identify a Performance Monitor component.
Usage constraints
The PMPIDR4 can be accessed through the external debug interface.
The accessibility to the PMPIDR4 by condition code is:
Off DLK OSLK EPMAD SLK Default
- - - - RO RO
C2.2 External register access permissions to the PMU registers on page C2-587 describes the
condition codes.
Configurations
The PMPIDR4 is in the Debug power domain.
Attributes
See the register summary in C10.9 Memory-mapped PMU register summary on page C10-714.
RES0
31 0
34
DES_2
78
Size
Figure C10-12 PMPIDR4 bit assignments
[31:8]
Reserved, RES0.
Size, [7:4]
0x0 Size of the component. Log2 the number of 4KB pages from the start of the
component to the end of the component ID registers.
DES_2, [3:0]
0x4 Arm Limited. This is the least significant nibble JEP106 continuation code.
The PMPIDR4 can be accessed through the external debug interface, offset 0xFD0.
