B2.6 AArch64 Cache maintenance operations
The following table shows the System instructions for cache and maintenance operations in AArch64
state.
See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile for more
information about these operations.
Table B2-5 AArch64 cache maintenance operations
Name Description
IC IALLUIS
Instruction cache invalidate all to PoU Inner Shareable
PoU = Point of Unification. PoU is set by the BROADCASTINNER signal and can be in the L1 data cache or outside
of the processor, in which case PoU is dependent on the external memory system.
IC IALLU
Instruction cache invalidate all to PoU
IC IVAU
Instruction cache invalidate by virtual address (VA) to PoU
DC IVAC
Data cache invalidate by VA to PoC
PoC = Point of Coherence. The PoC is always outside of the processor and depends on the external memory system.
DC ISW
Data cache invalidate by set/way
DC CSW
Data cache clean by set/way
DC CISW
Data cache clean and invalidate by set/way
DC ZVA
Data cache zero by VA
DC CVAC
Data cache clean by VA to PoC
DC CVAU
Data cache clean by VA to PoU
DC CIVAC
Data cache clean and invalidate by VA to PoC
B2 AArch64 system registers
B2.6 AArch64 Cache maintenance operations
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-369
Non-Confidential
