B2.61 AArch32 Instruction Set Attribute Register 4, EL1
The ID_ISAR4_EL1 characteristics are:
Purpose
Provides information about the instruction sets implemented by the processor in AArch32.
Usage constraints
This register is accessible as follows:
EL0 EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
- RO RO RO RO RO
Configurations
ID_ISAR4_EL1 is architecturally mapped to AArch32 register ID_ISAR4. See
B1.78 Instruction Set Attribute Register 4 on page B1-277.
Attributes
ID_ISAR4_EL1 is a 32-bit register.
31 24 23 20 19 16 15 12 11 8 7 4 3 0
SynchPrim_frac
SWP_frac
28 27
PSR_M Barrier SMC Writeback WithShifts Unpriv
Figure B2-34 ID_ISAR4_EL1 bit assignments
SWP_frac, [31:28]
Indicates support for the memory system locking the bus for SWP or SWPB instructions:
0x0 SWP and SWPB instructions not implemented.
PSR_M, [27:24]
Indicates the implemented M profile instructions to modify the PSRs:
0x0 None implemented.
SynchPrim_frac, [23:20]
This field is used with the ID_ISAR3.SynchPrim field to indicate the implemented
Synchronization Primitive instructions:
0x0 • The LDREX and STREX instructions.
• The CLREX, LDREXB, LDREXH, STREXB, and STREXH instructions.
• The LDREXD and STREXD instructions.
Barrier, [19:16]
Indicates the supported Barrier instructions in the A32 and T32 instruction sets:
0x1 The DMB, DSB, and ISB barrier instructions.
SMC, [15:12]
Indicates the implemented SMC instructions:
0x1 The SMC instruction.
