A.9 ACP interface signals
The AXI protocol supports clock, configuration, and data handling signals if the processor implements
the ACP slave interface to an external master to make coherent request to the shared L2 cache of the
cluster.
This interface exists only if the processor is configured to have the ACP interface.
All ACP channels must be balanced with respect to CLKIN and timed relative to ACLKENS.
Table A-11 ACP clock and Configuration signals
Signal Direction Description
ACLKENS Input AXI slave bus clock enable.
AINACTS Input
ACP master is inactive and is not participating in coherency. There must be no outstanding transactions
when the master asserts this signal, and while it is asserted the master must not send any new transactions:
0
ACP Master is active.
1
ACP Master is inactive.
This signal must be asserted before the processor enters the low-power L2 WFI state.
Table A-12 ACP write address channel signals
Signal Direction Description
AWREADYS Output Write address ready
AWVALIDS Input Write address valid
AWIDS[4:0] Input Write address ID
AWADDRS[39:0] Input Write address
AWLENS[7:0] Input Write burst length
AWCACHES[3:0] Input Write cache type
AWUSERS[1:0] Input
Write attributes:
[0] Inner Shareable.
[1] Outer Shareable.
AWPROTS[2:0] Input Write protection type
Table A-13 ACP write data channel signals
Signal Direction Description
WREADYS Output Write data ready
WVALIDS Input Write data valid
WDATAS[127:0] Input Write data
WSTRBS[15:0] Input Write byte-lane strobes
WLASTS Input Write data last transfer indication
