C11.9 Stall Control Register
The TRCSTALLCTLR characteristics are:
Purpose
Enables the ETM trace unit to stall the Cortex‑A35 processor if the ETM trace unit FIFO
overflows.
Usage constraints
• You must always program this register as part of trace unit initialization.
• Accepts writes only when the trace unit is disabled.
Configurations
Available in all configurations.
Attributes
See C11.1 ETM register summary on page C11-733.
RES0
31 07 4
RES0
3
ISTALL
89
LEVEL
RES0
2 1
Figure C11-8 TRCSTALLCTLR bit assignments
[31:9]
Reserved, RES0.
ISTALL, [8]
Instruction stall bit. Controls if the trace unit can stall the processor when the instruction trace
buffer space is less than LEVEL:
0 The trace unit does not stall the processor.
1 The trace unit can stall the processor.
[7:4]
Reserved, RES0.
LEVEL, [3:2]
Threshold level field. The field can support 4 monotonic levels from 0b00 to 0b11, where:
0b00 Zero invasion. This setting has a greater risk of an ETM trace unit FIFO overflow.
0b11 Maximum invasion occurs but there is less risk of a FIFO overflow.
[1:0]
Reserved, RES0.
The TRCSTALLCTLR can be accessed through the external debug interface, offset 0x02c.
