C1.6 Debug memory map
The basic memory map supports up to four cores in the cluster. You can configure the mapping as a v8 or
as a v7 Debug memory map.
The following table shows the address mapping for the debug APB components when you configure
them for a v8 Debug memory map. Each component in the table requires 4KB and uses the bottom 4KB
of each 64KB region. The remaining 60KB of each region is reserved. The table indicates the mapped
component if it is present, otherwise the field is reserved.
Table C1-3 Address mapping for APB components in a v8 Debug memory map
Address offset [21:0] Mapped to
0x000000 - 0x000FFF APB ROM table for the processor
0x010000 - 0x010FFF Core 0 Debug
0x020000 - 0x020FFF Core 0 CTI
0x030000 - 0x030FFF Core 0 PMU
0x040000 - 0x040FFF Core 0 Trace
0x041000 - 0x10FFFF Reserved
0x110000 - 0x110FFF Core 1 Debug
0x120000 - 0x120FFF Core 1 CTI
0x130000 - 0x130FFF Core 1 PMU
0x140000 - 0x140FFF Core 1 Trace
0x141000 - 0x20FFFF Reserved
0x210000 - 0x210FFF Core 2 Debug
0x220000 - 0x220FFF Core 2 CTI
0x230000 - 0x230FFF Core 2 PMU
0x240000 - 0x240FFF Core 2 Trace
0x241000 - 0x30FFFF Reserved
0x310000 - 0x310FFF Core 3 Debug
0x320000 - 0x320FFF Core 3 CTI
0x330000 - 0x330FFF Core 3 PMU
0x340000 - 0x340FFF Core 3 Trace
0x341000 - 0x3FFFFF Reserved
The following table shows the address mapping for the debug components when you configure them for
a v7 Debug memory map. The table indicates the mapped component if it is present, otherwise the field
is reserved.
C1 Debug
C1.6 Debug memory map
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C1-581
Non-Confidential
