Table C1-4 Address mapping for APB components in a v7 Debug memory map
Address offset [21:0] Mapped to
0x00000 - 0x00FFF APB ROM table for the processor
0x01000 - 0x07FFF Reserved for other debug components
0x08000 - 0x0FFFF Reserved for future expansion
0x10000 - 0x10FFF Core 0 Debug
0x11000 - 0x11FFF Core 0 PMU
0x12000 - 0x12FFF Core 1 Debug
0x13000 - 0x13FFF Core 1 PMU
0x14000 - 0x14FFF Core 2 Debug
0x15000 - 0x15FFF Core 2 PMU
0x16000 - 0x16FFF Core 3 Debug
0x17000 - 0x17FFF Core 3 PMU
0x18000 - 0x18FFF Core 0 CTI
0x19000 - 0x19FFF Core 1 CTI
0x1A000 - 0x1AFFF Core 2 CTI
0x1B000 - 0x1BFFF Core 3 CTI
0x1C000 - 0x1CFFF Core 0 Trace
0x1D000 - 0x1DFFF Core 1 Trace
0x1E000 - 0x1EFFF Core 2 Trace
0x1F000 - 0x1FFFF Core 3 Trace
C1 Debug
C1.6 Debug memory map
