B1.20 AArch32 Identification registers
The following table shows the identification registers.
Table B1-19 Identification registers
Name CRn Op1 CRm Op2 Reset Description
MIDR c0 0 c0 0
0x411FD040
B1.96 Main ID Register on page B1-313
CTR 1
0x84448004
B1.46 Cache Type Register on page B1-219
TCMTR 2
0x00000000
B1.108 TCM Type Register on page B1-339
TLBTR 3
0x00000000
B1.109 TLB Type Register on page B1-340
MPIDR 5 -
B1.97 Multiprocessor Affinity Register on page B1-315
The reset value depends on the primary inputs, CLUSTERIDAFF1 and
CLUSTERIDAFF2, and the number of cores that the device implements.
REVIDR 6
0x00000000
B1.102 Revision ID Register on page B1-325
ID_PFR0 c1 0
0x00000131
B1.84 Processor Feature Register 0 on page B1-289
ID_PFR1 1
0x10011011
B1.85 Processor Feature Register 1 on page B1-291
Bits [31:28] are 0x1 if the GIC CPU interface is implemented and enabled,
and 0x0 otherwise.
ID_DFR0 2
0x03010066
B1.73 Debug Feature Register 0 on page B1-267
Bits [19:16] are 0x1 if ETM is implemented, and 0x0 otherwise.
ID_AFR0 3
0x00000000
B1.72 Auxiliary Feature Register 0 on page B1-266
ID_MMFR0 4
0x10201105
B1.80 Memory Model Feature Register 0 on page B1-281
ID_MMFR1 5
0x40000000
B1.81 Memory Model Feature Register 1 on page B1-283
ID_MMFR2 6
0x01260000
B1.82 Memory Model Feature Register 2 on page B1-285
ID_MMFR3 7
0x02102211
B1.83 Memory Model Feature Register 3 on page B1-287
ID_ISAR0 c2 0
0x02101110
B1.74 Instruction Set Attribute Register 0 on page B1-269
ID_ISAR1 1
0x13112111
B1.75 Instruction Set Attribute Register 1 on page B1-271
ID_ISAR2 2
0x21232042
B1.76 Instruction Set Attribute Register 2 on page B1-273
ID_ISAR3 3
0x01112131
B1.77 Instruction Set Attribute Register 3 on page B1-275
ID_ISAR4 4
0x00011142
B1.78 Instruction Set Attribute Register 4 on page B1-277
