C11.18 Sequencer Reset Control Register
The TRCSEQRSTEVR characteristics are:
Purpose
Resets the sequencer to state 0.
Usage constraints
• Accepts writes only when the trace unit is disabled.
• If the sequencer is used, you must program all sequencer state transitions with a valid event.
Configurations
Available in all configurations.
Attributes
See C11.1 ETM register summary on page C11-733.
31 0
RES0RES0 RESETSEL
8 7 4 36
RESETTYPE
Figure C11-17 TRCSEQRSTEVR bit assignments
[31:8]
Reserved, RES0.
RESETTYPE, [7]
Selects the resource type to move back to state 0:
0 Single selected resource.
1 Boolean combined resource pair.
[6:4]
Reserved, RES0.
RESETSEL, [3:0]
Selects the resource number, based on the value of RESETTYPE:
When RESETTYPE is 0, selects a single selected resource from 0-15 defined by bits[3:0].
When RESETTYPE is 1, selects a Boolean combined resource pair from 0-7 defined by
bits[2:0].
The TRCSEQRSTEVR can be accessed through the external debug interface, offset 0x118.
