B3.1 CPU interface register summary
Each CPU interface block provides the interface for a Cortex‑A35 processor that interfaces with a GIC
distributor within the system.
Each CPU interface provides a programming interface for:
• Enabling the signaling of interrupt requests by the CPU interface.
• Acknowledging an interrupt.
• Indicating completion of the processing of an interrupt.
• Setting an interrupt priority mask for the processor.
• Defining the preemption policy for the processor.
• Determining the highest priority pending interrupt for the processor.
• Generating SGIs.
For more information on the CPU interface, see the Arm
®
Generic Interrupt Controller Architecture
Specification.
The following table lists the registers for the CPU interface.
All the registers in the following table are word-accessible. Registers not described in this table are RES0.
See the Arm
®
Generic Interrupt Controller Architecture Specification for more information.
Table B3-1 CPU interface register summary
Offset Name Type Reset Description
0x0000
GICC_CTLR RW
0x00000000
CPU Interface Control Register
0x0004
GICC_PMR RW
0x00000000
Interrupt Priority Mask Register
0x0008
GICC_BPR RW
0x00000002 (Secure)
0x00000003 (Non-secure)
Binary Point Register
0x000C
GICC_IAR RO
-
Interrupt Acknowledge Register
0x0010
GICC_EOIR WO
-
End Of Interrupt Register
0x0014
GICC_RPR RO
0x000000FF
Running Priority Register
0x0018
GICC_HPPIR RO
0x000003FF
Highest Priority Pending Interrupt Register
0x001C
GICC_ABPR RW
0x00000003
Aliased Binary Point Register
0x0020
GICC_AIAR RO
-
Aliased Interrupt Acknowledge Register
0x0024
GICC_AEOIR WO
-
Aliased End of Interrupt Register
0x0028
GICC_AHPPIR RO
0x000003FF
Aliased Highest Priority Pending Interrupt Register
0x00D0
GICC_APR0 RW
0x00000000
B3.2 Active Priority Register on page B3-561
0x00E0
GICC_NSAPR0 RW
0x00000000
Non-secure Active Priority Register
0x00FC
GICC_IIDR RO
0x0044343B
B3.3 CPU Interface Identification Register on page B3-562
0x1000
GICC_DIR WO - Deactivate Interrupt Register
B3 GIC registers
B3.1 CPU interface register summary
