A10.5 CHI transactions
CHI transactions are sent to a specific node in the interconnect based on the following criteria:
• Type of access.
• Address of the access.
• Settings of the System Address Map.
Addresses that map to an HN-F node can be marked as cacheable memory in the page tables, and can
take part in the cache coherency protocol. Addresses that map to an HN-I or MN must be marked as
device or non-cacheable memory.
Table A10-5 CHI transaction IDs
Transaction ID Description
000nnxxx Transaction from core nn. Can be a:
• Read transaction.
• Write transaction.
• Cache maintenance transaction.
• DVM transaction.
• Barrier transaction.
001001xx Transaction from the ACP interface. Can be a read or write.
00101110 Barrier generated in response to a DVM sync snoop from the interconnect.
0100xxxx Eviction from L1 or L2 cache. The number of IDs used depends on the configuration.
Table A10-6 CHI transactions
Transaction Operation
ReadNoSnp Non-cacheable loads or instruction fetches. Linefills of non-shareable cache lines into L1 or L2.
ReadOnce Cacheable loads that are not allocating into the cache, or cacheable instruction fetches when there is no L2 cache.
ReadClean Not used.
ReadShared L1 Data linefills started by a load instruction, or L2 linefills started by an instruction fetch.
ReadUnique L1 Data linefills started by a store instruction.
CleanUnique Store instructions that hit in the cache but the line is not in a unique coherence state.
MakeUnique Store instructions of a full cache line of data, that miss in the caches, and are allocating into the L2 cache.
CleanShared Cache maintenance instructions.
CleanInvalid Cache maintenance instructions.
MakeInvalid Cache maintenance instructions.
DVMOp TLB and instruction cache maintenance instructions.
EOBarrier DMB instructions.
ECBarrier DSB instructions. DVM sync snoops received from the interconnect.
WriteNoSnpPtl Non-cacheable store instructions.
WriteNoSnpFull Non-cacheable store instructions, or evictions of non-shareable cache lines from the L1 and L2 cache.
WriteUniqueFull Cacheable writes of a full cache line, that are not allocating into L1 or L2 caches, for example streaming writes.
WriteUniquePtl Cacheable writes of less than a full cache line that are not allocating into L1 or L2.
A10 CHI Master Interface
A10.5 CHI transactions
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
A10-131
Non-Confidential
