B2.70 IFSR32_EL2 with Short-descriptor translation table format
IFSR32_EL32 has a specific format when using the Short-descriptor translation table format.
The following figure shows the IFSR32_EL2 bit assignments when using the Short-descriptor translation
table format.
31 13 12 11 10 9 8 4 3 0
RES0 0 RES0 FS[3:0]
ExT FS[4]
RES0
Figure B2-42 IFSR32_EL2 bit assignments for Short-descriptor translation table format
[31:13]
Reserved, RES0.
ExT, [12]
External abort type. This field indicates whether an AXI Decode or Slave error caused an abort:
0 External abort marked as DECERR.
1 External abort marked as SLVERR.
For aborts other than external aborts this bit always returns 0.
[11]
Reserved, RES0.
FS[4], [10]
Part of the Fault Status field. See bits [3:0] in this table.
[9]
RAZ.
[8:5]
Reserved, RES0.
FS[3:0], [4:0]
Fault Status bits. This field indicates the type of exception generated. Any encoding not listed is
reserved.
0b00010 Debug event.
0b00011 Access flag fault, section.
0b00101 Translation fault, section.
0b00110 Access flag fault, page.
0b00111 Translation fault, page.
0b01000 Synchronous external abort, non-translation.
0b01001 Domain fault, section.
0b01011 Domain fault, page.
0b01100 Synchronous external abort on translation table walk, first level.
0b01101 Permission Fault, Section.
0b01110 Synchronous external abort on translation table walk, second Level.
0b01111 Permission fault, page.
0b10000 TLB conflict abort.
