C9.8 ROM Table Peripheral Identification Register 2
The ROMPIDR2 characteristics are:
Purpose
Provides information to identify an external debug component.
Usage constraints
This register is accessible as follows:
Off DLK OSLK EDAD SLK Default
- - - - - RO
C1.4 External access permissions to debug registers on page C1-579 describes the condition
codes.
Configurations
The ROMPIDR2 is in the Debug power domain.
Attributes
See C9.3 ROM table register summary on page C9-672.
RES0
31 0
34
DES_1
78
Revision
JEDEC
2
Figure C9-4 ROMPIDR2 bit assignments
[31:8]
Reserved, RES0.
Revision, [7:4]
0x3 r1p0.
JEDEC, [3]
0b1 RAO. Indicates a JEP106 identity code is used.
DES_1, [2:0]
0b011 Designer, most significant bits of JEP106 ID code. For Arm Limited.
The ROMPIDR2 can be accessed through the external debug interface, offset 0xFE8.
