B2.72 Interrupt Status Register, EL1
The ISR_EL1 characteristics are:
Purpose
Shows whether an IRQ, FIQ, or external abort is pending. An indicated pending abort might be
a physical abort or a virtual abort.
Usage constraints
This register is accessible as follows:
EL0 EL1
(NS)
EL1
(S)
EL2
EL3
(SCR.NS = 1)
EL3
(SCR.NS = 0)
- RO RO RO RO RO
Configurations
ISR_EL1 is architecturally mapped to AArch32 register ISR. See B1.90 Interrupt Status
Register on page B1-299.
Attributes
ISR_EL1 is a 32-bit register.
31 9 8 7 6 5
0
ReservedFIA
Reserved
Figure B2-44 ISR_EL1 bit assignments
[31:9]
Reserved, RES0.
A, [8]
External abort pending bit:
0 No pending external abort.
1 An external abort is pending.
I, [7]
IRQ pending bit. Indicates whether an IRQ interrupt is pending:
0 No pending IRQ.
1 An IRQ interrupt is pending.
F, [6]
FIQ pending bit. Indicates whether an FIQ interrupt is pending:
0 No pending FIQ.
1 An FIQ interrupt is pending.
[5:0]
Reserved, RES0.
To access the ISR_EL1:
MRS <Xt>, ISR_EL1 ; Read ISR_EL1 into Xt
B2 AArch64 system registers
B2.72 Interrupt Status Register, EL1
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-484
Non-Confidential
