A8.3 AXI transactions
The processor generates only a subset of all possible AXI transactions on the AXI master interface.
The processor does not generate any FIXED bursts and all WRAP bursts fetch a complete cache line
starting with the critical word first. A burst does not cross a cache line boundary.
The cache linefill fetch length is always 64 bytes.
For WriteBack transfers the supported transfers are:
• WRAP 4 128-bit for read transfers (linefills).
• INCR 4 128-bit for write transfers (evictions).
• INCR N (N:1, 2, or 4) 128-bit write transfers (read allocate).
For Non-cacheable transactions:
• WRAP 4 128-bit for read transfers.
• INCR N (N:1, 2, or 4) 128-bit for write transfers.
• INCR N (N:1, 2, or 4) 128-bit for read transfers.
• INCR 1 32-bit, 64-bit, and 128-bit for read transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit for write transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit for exclusive write transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit for exclusive read transfers.
For Device transactions:
• INCR N (N:1, 2, or 4) 128-bit read transfers.
• INCR N (N:1, 2, or 4) 128-bit write transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit read transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit write transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit exclusive read transfers.
• INCR 1 8-bit, 16-bit, 32-bit, 64-bit, and 128-bit exclusive write transfers.
For translation table walk transactions INCR 1 32-bit, and 64-bit read transfers.
The following points apply to AXI transactions:
• WRAP bursts are only 128-bit.
• INCR 1 can be any size for read or write.
• INCR burst, more than one transfer, are only 128-bit.
• No transaction is marked as FIXED.
• Write transfers with none, some, or all byte strobes LOW can occur.
External memory accesses generate the following transactions in an implementation configured with an
AXI master interface.
Table A8-2 AXI transactions
Attributes AXI transaction
Memory type Shareability Load Store Load exclusive Store exclusive
Device - Read Write Read with
ARLOCKM set HIGH
Write with AWLOCKM
set HIGH
Normal, inner Non-cacheable, outer Non-
cacheable
Non-shared Read Write Read Write
Inner-shared Read with
ARLOCKM set HIGH
Write with ARLOCKM set
HIGH
Outer-shared
