C12.15 CTI Component Identification Register 2
The CTICIDR2 characteristics are:
Purpose
Provides information to identify a CTI component.
Usage constraints
The accessibility of CTICIDR2 by condition code is:
Off DLK OSLK EPMAD SLK Default
- - - - RO RO
C12.2 External register access permissions to the CTI registers on page C12-828 describes the
condition codes.
Configurations
CTICIDR2 is in the Debug power domain.
CTICIDR2 is optional to implement in the external register interface.
Attributes
See the register summary in C12.1 Cross trigger register summary on page C12-826.
RES0
31 0
PRMBL_2
78
Figure C12-10 CTICIDR2 bit assignments
[31:8]
Reserved, RES0.
PRMBL_2, [7:0]
0x05 Preamble byte 2.
CTICIDR2 can be accessed through the external debug interface, offset 0xFF8.
C12 CTI registers
C12.15 CTI Component Identification Register 2
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C12-842
Non-Confidential
