A7.4 Memory type information exported from the processor
The processor makes attribute information about memory types available through signals for
interconnects or bus protocols that require such information.
Some interconnects or bus protocols might require more information about the memory type and, for
these cases, the cluster exports the memory attribute information from the translation tables stored in the
TLB. These signals are for information only, and do not form part of the AXI, ACE, or CHI protocols.
• In an AXI or ACE configuration, there is a RDMEMATTR bus for the read channel and a
WRMEMATTR bus for the write channel.
• In a CHI configuration, there is a single REQMEMATTR bus.
Table A7-2 Bus encoding for memory attributes
Bits Encoding Notes
[7]
Outer shareable.
Always set for device memory or
memory that is both inner and outer
non-cacheable.
Shareability information is not recorded in the L1 data cache for
implementations that use the mini-SCU. WRMEMATTR[7] is 0b0 for L1 data
cache evictions in these implementations.
[6:3]
Outer memory type, or device type.
If bits[1:0] indicate Device, then:
0b0000
nGnRnE.
0b0100
nGnRE.
0b1000
nGRE.
0b1100
GRE.
If bits[1:0] indicate Normal, then:
0b0100
NC.
0b10RW
WT.
0b11RW
WB.
Where R is read allocate hint, W is
write allocate hint.
If an Armv7 architecture operating system runs on the processor, the Device
memory type matches the nGnRE encoding and the Strongly-Ordered memory
type matches the nGnRnE memory type.
Outer read allocate hint information is not recorded in the L1 or L2 data caches.
WRMEMATTR[4] and REQMEMATTR[4] are set to 0b1 for data cache
evictions.
[2]
Inner shareable.
Anything with bit[7] set must also
have bit[2] set.
Shareability information is not recorded in the L1 data cache for
implementations that use the mini-SCU. WRMEMATTR[2] is 0b0 for L1 data
cache evictions in these implementations.
[1:0]
Inner memory type:
0b00
Device.
0b01
NC.
0b10
WT.
0b11
WB.
A7 L2 Memory System
A7.4 Memory type information exported from the processor
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
A7-102
