ARM Cortex-A35 User Manual

Table C12-1 Cross trigger register summary (continued)
Offset Name Type Description
0x144
ASICCTL RW CTI External Multiplexer Control Register
0x148-0xF7C
- - Reserved
0xF00
CTIITCTRL RW C12.4 CTI Integration Mode Control Register on page C12-831
0xF04-0xFA4
- - Reserved
0xFA0
CTICLAIMSET RW CTI Claim Tag Set Register
0xFA4
CTICLAIMCLR RW CTI Claim Tag Clear Register
0xFA8
CTIDEVAFF0 RO CTI Device Affinity Register 0
0xFAC
CTIDEVAFF1 RO CTI Device Affinity Register 1
0xFB0
CTILAR WO CTI Lock Access Register
0xFB4
CTILSR RO CTI Lock Status Register
0xFB8
CTIAUTHSTATUS RO CTI Authentication Status Register
0xFBC
CTIDEVARCH RO CTI Device Architecture Register
0xFC0
CTIDEVID2 RO CTI Device ID Register 2
0xFC4
CTIDEVID1 RO CTI Device ID Register 1
0xFC8
CTIDEVID RO C12.3 CTI Device Identification Register on page C12-829
0xFCC
CTIDEVTYPE RO CTI Device Type Register
0xFD0
CTIPIDR4 RO C12.10 CTI Peripheral Identification Register 4 on page C12-837
0xFD4
CTIPIDR5 RO C12.11 CTI Peripheral Identification Register 5-7 on page C12-838
0xFD8
CTIPIDR6 RO
0xFDC
CTIPIDR7 RO
0xFE0
CTIPIDR0 RO C12.6 CTI Peripheral Identification Register 0 on page C12-833
0xFE4
CTIPIDR1 RO C12.7 CTI Peripheral Identification Register 1 on page C12-834
0xFE8
CTIPIDR2 RO C12.8 CTI Peripheral Identification Register 2 on page C12-835
0xFEC
CTIPIDR3 RO C12.9 CTI Peripheral Identification Register 3 on page C12-836
0xFF0
CTICIDR0 RO C12.13 CTI Component Identification Register 0 on page C12-840
0xFF4
CTICIDR1 RO C12.14 CTI Component Identification Register 1 on page C12-841
0xFF8
CTICIDR2 RO C12.15 CTI Component Identification Register 2 on page C12-842
0xFFC
CTICIDR3 RO C12.16 CTI Component Identification Register 3 on page C12-843
C12 CTI registers
C12.1 Cross trigger register summary
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C12-827
Non-Confidential
