Table C11-1 ETM trace unit register summary (continued)
Name Type Description
TRCIDR10 RO C11.27 ID Register 10 on page C11-768
TRCIDR11 RO C11.28 ID Register 11 on page C11-769
TRCIDR12 RO C11.29 ID Register 12 on page C11-770
TRCIDR13 RO C11.30 ID Register 13 on page C11-771
TCRIMSPEC0 RW C11.31 Implementation Specific Register 0 on page C11-772
TRCIDR0 RO C11.32 ID Register 0 on page C11-773
TRCIDR1 RO C11.33 ID Register 1 on page C11-775
TRCIDR2 RO C11.34 ID Register 2 on page C11-776
TRCIDR3 RO C11.35 ID Register 3 on page C11-778
TRCIDR4 RO C11.36 ID Register 4 on page C11-780
TRCIDR5 RO C11.37 ID Register 5 on page C11-782
TRCRSCTLRn RW C11.38 Resource Selection Control Registers 2-16 on page C11-784, n is 2, 15
TRCSSCCR0 RW C11.39 Single-Shot Comparator Control Register 0 on page C11-785
TRCSSCSR0 RW, RO C11.40 Single-Shot Comparator Status Register 0 on page C11-786
TRCOSLAR WO C11.41 OS Lock Access Register on page C11-787
TRCOSLSR RO C11.42 OS Lock Status Register on page C11-788
TRCPDCR RW C11.43 Power Down Control Register on page C11-789
TRCPDSR RO C11.44 Power Down Status Register on page C11-790
TRCACVRn RW C11.45 Address Comparator Value Registers 0-7 on page C11-791
TRCACATRn RW C11.46 Address Comparator Access Type Registers 0-7 on page C11-792>
TRCCIDCVR0 RW C11.47 Context ID Comparator Value Register 0 on page C11-794
TRCVMIDCVR0 RW C11.48 VMID Comparator Value Register 0 on page C11-795
TRCCIDCCTLR0 RW C11.49 Context ID Comparator Control Register 0 on page C11-796
TRCITATBIDR RW C11.50 Integration ATB Identification Register on page C11-797
TRCITIDATAR WO C11.51 Integration Instruction ATB Data Register on page C11-798
TRCITIATBINR RO C11.52 Integration Instruction ATB In Register on page C11-799
TRCITIATBOUTR WO C11.53 Integration Instruction ATB Out Register on page C11-800
TRCITCTRL RW C11.54 Integration Mode Control Register on page C11-801
TRCCLAIMSET RW C11.55 Claim Tag Set Register on page C11-802
TRCCLAIMCLR RW C11.56 Claim Tag Clear Register on page C11-803
TRCDEVAFF0 RO C11.57 Device Affinity Register 0 on page C11-804
TRCDEVAFF1 RO C11.58 Device Affinity Register 1 on page C11-806
TRCLAR WO C11.59 Software Lock Access Register on page C11-807
TRCLSR RO C11.60 Software Lock Status Register on page C11-808
TRCAUTHSTATUS RO C11.61 Authentication Status Register on page C11-809
C11 ETM registers
C11.1 ETM register summary
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C11-734
Non-Confidential
