Trap Performance Monitor Control Register accesses:
0 Has no effect on PMCR accesses.
1 Trap valid Non-secure PMCR accesses to Hyp mode.
When this bit is set to 1, any valid Non-secure access to the PMCR is trapped to Hyp mode.
This bit resets to 0. See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A
architecture profile for more information.
HPMN, [4:0]
Hyp Performance Monitor count. Defines the number of Performance Monitors counters that are
accessible from Non-secure EL1 and EL0 modes if unprivileged access is enabled.
In Non-secure state, HPMN divides the Performance Monitors counters as follows. If software
is accessing Performance Monitors counter n then, in Non-secure state:
For example, If PMnEVCNTR is performance monitor counter n then, in Non-secure state:
• If n is in the range 0 ≤ n < HPMN, the counter is accessible from EL1 and EL2, and from
EL0 if unprivileged access to the counters is enabled.
•
If
n is in the range HPMN ≤
n <PMCR.N, the counter is accessible only from EL2. The
HPME bit enables access to the counters in this range.
If this field is set to 0, or to a value larger than PMCR.N, then the behavior in Non-secure EL0
and EL1 is CONSTRAINED UNPREDICTABLE, and one of the following must happen:
• The number of counters accessible is an UNKNOWN non-zero value less than PMCR.N.
• There is no access to any counters.
For reads of HDCR.HPMN by EL2 or higher, if this field is set to 0 or to a value larger than
PMCR.N, the processor must return a CONSTRAINED UNPREDICTABLE value being one of:
• PMCR.N.
• The value that was written to HDCR.HPMN.
• (The value that was written to HDCR.HPMN) modulo 2h, where h is the smallest number of
bits required for a value in the range 0 to PMCR.N.
This field resets to 0x6.
To access the HDCR:
MRC p15,4,<Rt>,c1,c1,1 ; Read HDCR into Rt
MCR p15,4,<Rt>,c1,c1,1 ; Write Rt to HDCR
Register access is encoded as follows:
Table B1-48 HDCR access encoding
coproc opc1 CRn CRm opc2
1111 100 0001 0001 001
B1 AArch32 system registers
B1.63 Hyp Debug Control Register
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B1-250
Non-Confidential
