Table A-4 GIC signals (continued)
Signal Direction Description
nVIRQ[CN:0] Input
Virtual IRQ request. Active-LOW, level sensitive, asynchronous interrupt request:
0
Activate interrupt.
1
Do not activate interrupt.
The processor treats nVIRQ as level-sensitive. nVIRQ must be asserted until the processor
acknowledges the interrupt. If the GIC is enabled by tying GICCDISABLE LOW, nVIRQ
must be tied off to HIGH. If the GIC is disabled by tying GICCDISABLE HIGH, nVIRQ
can be driven by an external GIC in the SoC.
nVSEI[CN:0] Input
Virtual System Error Interrupt request. Active-LOW, edge sensitive:
0
Activate virtual SEI request.
1
Do not activate virtual SEI request.
The processor treats nVSEI as edge-sensitive. The nVSEI signal must be sent as a pulse to
the processor.
Asserting nVSEI causes one of the following to occur:
• Asynchronous Data Abort, if taken to AArch32. The DFSR.FS field is set to indicate an
Asynchronous External Abort.
• SError interrupt, if taken to AArch64. The ESR_EL1.ISS field is set.
nREI[CN:0] Input
RAM Error Interrupt request. Active-LOW, edge sensitive:
0
Activate REI request. Reports an asynchronous RAM error in the system.
1
Do not activate REI request.
The processor treats nREI as edge-sensitive. The nREI signal must be sent as a pulse to the
processor.
Asserting the nREI input causes one of the following to occur:
• Asynchronous Data Abort, if taken to AArch32. The DFSR.FS field is set to indicate an
Asynchronous parity error on memory access.
• SError interrupt, if taken to AArch64. The ESR_ELx.ISS field is set.
nVCPUMNTIRQ[CN:0] Output Virtual CPU interface maintenance interrupt PPI output.
PERIPHBASE[39:18] Input
Specifies the base address for the GIC registers. This value is sampled into CBAR at reset.
GICCDISABLE Input
Globally disables the GIC CPU interface logic and routes the external signals directly to the
processor:
0
Enable the GIC CPU interface logic.
1
Disable the GIC CPU interface logic and route the legacy nIRQ, nFIQ, nVIRQ,
and nVFIQ signals directly to the processor. Drive this signal HIGH when you are
using a legacy interrupt controller such as the GIC-400 which does not support
GICv3 or GICv4.
Table A-5 AXI4 Stream Protocol signals for messages from the Distributor to the GIC CPU Interface
Signal Direction Description
ICDTVALID Input Indicates that the master is driving a valid transfer.
ICDTREADY Output Indicates that the slave can accept a transfer in the current cycle.
A Signal Descriptions
A.5 GIC signals
