NETGEAR M4100 Series ProSAFE User Manual

Green Ethernet Commands
528
M4100 Series ProSAFE Managed Switches
Note: Executing the clear green-mode statistics command clears
only the EEE Transmit, Receive LPI event count, LPI duration, and
Cumulative Energy Savings Estimates of the port. Other status
parameters listed in the previous table remain unaffected after you
executed the clear green-mode statistics command.
Command example:
(NETGEAR Switch) #show green-mode
Current Power Consumption (mW).............. XX
Power Saving (%)............................ XX
Cumulative Energy Saving /Stack (W * H)... XX
Unit Green Ethernet Features Supported
---- --------------------------------
1 Energy-Detect EEE LPI-History LLDP-Cap-Exchg Pwr-Usg-Est
Remote Tw_sys_rx
(microsec)
Integer that indicates the value of Tw_sys that the remote system requests from the
local system. This value maps from the aLldpXdot3RemRxTwSys attribute.
Remote Tw_sys_rx Echo
(microsec)
Integer that indicates the value of Receive Tw_sys echoed back by the remote
system. This value maps from the aLldpXdot3RemRxTwSysEcho attribute.
Remote Fallback Tw_sys
(microsec)
Integer that indicates the value of fallback Tw_sys that the remote system is
advertising. This attribute maps to the variable RemFbSystemValue as defined in
78.4.2.3.
Tx_dll_enabled Initialization status of the EEE transmit Data Link Layer management function on the
local system.
Tx_dll_ready Data Link Layer ready: This variable indicates that the tx system initialization is
complete and is ready to update/receive LLDPDU containing EEE TLV. This variable
is updated by the local system software.
Rx_dll_enabled Status of the EEE capability negotiation on the local system.
Rx_dll_ready Data Link Layer ready: This variable indicates that the rx system initialization is
complete and is ready to update/receive LLDPDU containing EEE TLV. This variable
is updated by the local system software.
Cumulative Energy
Saving
Estimated Cumulative energy saved on this port in (Watts * hours) due to all green
modes enabled
Time Since Counters
Last Cleared
Time Since Counters Last Cleared (since the time of power up, or after 'clear eee
counters' is executed)
Field Definition
