T
o access the CSSELR:
MRC p15, 2, <Rt>, c0, c0, 0; Read CSSELR into Rt
MCR p15, 2, <Rt>, c0, c0, 0; Write Rt to CSSELR
Register access is encoded as follows:
T
able B1-39 CSSELR access encoding
coproc
opc1
CRn
CRm
opc2
1
11
1
010
0000
0001
000
B1 AArch32 system registers
B1.45 Cache Size Selection Register
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B1-218
Non-Confidential
217
219
