T
o access the RMR:
MRC p15,0,<Rt>,c12,c0,2 ; Read RMR into Rt
MCR p15,0,<Rt>,c12,c0,2 ; Write Rt to RMR
Register access is encoded as follows:
T
able B1-88 RMR access encoding
coproc
opc1
CRn
CRm
opc2
1
11
1
000
1100
0000
010
B1 AArch32 system registers
B1.103 Reset Management Register
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B1-327
Non-Confidential
326
328
