ARM Cortex-A35 User Manual

This field is RO.
SCU-L2 Cache Protection, [21]
SCU-L2 Cache Protection. L2 cache is implemented:
0 Without ECC.
1 With ECC.
This field is RO.
[20:6]
Reserved, RES0.
L2 data RAM input latency, [5]
L2 data RAM input latency:
0 1-cycle input delay from L2 data RAMs.
1 2-cycle input delay from L2 data RAMs.
This field is RO.
[4:1]
Reserved, RES0.
L2 data RAM output latency, [0]
L2 data RAM output latency:
0 2-cycle output delay from L2 data RAMs.
1 3-cycle output delay from L2 data RAMs.
This field is RO.
To access the L2CTLR_EL1:
MRS <Xt>, S3_1_C11_C0_2 ; Read L2CTLR_EL1 into Xt
MSR S3_1_C11_C0_2, <Xt>; Write Xt to L2CTLR_EL1
Register access is encoded as follows:
Table B2-65 L2CTLR_EL1 access encoding
op0 op1 CRn CRm op2
11 001 1011 0000 010
B2 AArch64 system registers
B2.74 L2 Control Register, EL1
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-490
Non-Confidential
