[29:25]
Reserved, RES0.
MT, [24]
Indicates whether the lowest level of affinity consists of logical cores that are implemented
using a multi-threading type approach. This value is:
0 Performance of cores at the lowest affinity level is largely independent.
Aff2, [23:16]
Affinity level 2. Second highest level affinity field.
Indicates the value read in the CLUSTERIDAFF2 configuration signal.
Aff1, [15:8]
Affinity level 1. Third highest level affinity field.
Indicates the value read in the CLUSTERIDAFF1 configuration signal.
Aff0, [7:0]
Affinity level 0. Lowest level affinity field.
Indicates the core number in the Cortex‑A35 processor. The possible values are:
0x0 A cluster with one core only.
0x0, 0x1 A cluster with two cores.
0x0, 0x1, 0x2 A cluster with three cores.
0x0, 0x1, 0x2, 0x3 A cluster with four cores.
To access the MPIDR_EL1:
MRS <Xt>, MPIDR_EL1 ; Read MPIDR_EL1 into Xt
Register access is encoded as follows:
Table B2-78 MPIDR_EL1 access encoding
op0 op1 CRn CRm op2
11 000 0000 0000 101
The EDDEVAFF0 and EDDEVAFF1 can be accessed through the external debug interface, offsets 0xFA8
and 0xFAC respectively.
B2 AArch64 system registers
B2.84 Multiprocessor Affinity Register, EL1
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-513
Non-Confidential
