T
o access the RMR_EL3:
MRS <Xt>, RMR_EL3 ; Read RMR_EL3 into Xt
MSR RMR_EL3, <Xt> ; Write Xt to RMR_EL3
Register access is encoded as follows:
T
able B2-81 RMR_EL3 access encoding
op0
op1
CRn
CRm
op2
1
1
110
1100
0000
010
B2 AArch64 system registers
B2.87 Reset Management Register
, EL3
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-520
Non-Confidential
519
521
