T
o access the TCR_EL3:
MRS <Xt>, TCR_EL3 ; Read EL3 Translation Control Register
MRS TCR_EL3, <Xt> ; Read EL3 Translation Control Register
Register access is encoded as follows:
T
able B2-89 TCR_EL3 access encoding
op0
op1
CRn
CRm
op2
1
1
110
0010
0000
010
B2 AArch64 system registers
B2.96 T
ranslation Control Register
, EL3
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-545
Non-Confidential
544
546
