T
o access the DBGWCR
n
_EL1:
MRS <Xt>, DBGWCR
n
_EL1; Read Debug Watchpoint Control Register
n
MSR DBGWCR
n
_EL1, <Xt>; Write
Debug Watchpoint Control Register
n
The DBGWCR
n
_EL1 can be accessed through the external debug interface, offset
0x8n8
. The range of
n
for DBGWCRn_EL1 is 0 to 3.
C7 AArch64 debug registers
C7.3 Debug Watchpoint Control Registers, EL1
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C7-641
Non-Confidential
