ARM Cortex-A35 User Manual

Table A-38 CHI receive snoop virtual channel signals
Signal Direction Description
RXSNPFLITPEND Input Receive snoop flit pending
RXSNPFLITV Input Receive snoop flit valid
RXSNPFLIT[64:0] Input Receive snoop flit
RXSNPLCRDV Output Receive snoop link-layer credit valid
Table A-39 CHI receive response virtual channel signals
Signal Direction Description
RXRSPFLITPEND Input Receive response flit pending
RXRSPFLITV Input Receive response flit valid
RXRSPFLIT[44:0] Input Receive response flit
RXRSPLCRDV Output Receive response link-layer credit valid
Table A-40 CHI receive Data virtual channel signals
Signal Direction Description
RXDATFLITPEND Input Receive data flit pending
RXDATFLITV Input Receive data flit valid
RXDATFLIT[193:0] Input Receive data flit
RXDATLCRDV Output Receive data link-layer credit valid
Table A-41 CHI system address map signals
Signal Direction Description
SAMADDRMAP0[1:0] Input Region mapping, 0 – 512MB
SAMADDRMAP1[1:0] Input Region mapping, 512MB – 1GB
SAMADDRMAP2[1:0] Input Region mapping, 1GB – 1.5GB
SAMADDRMAP3[1:0] Input Region mapping, 1.5GB – 2GB
SAMADDRMAP4[1:0] Input Region mapping, 2GB – 2.5GB
SAMADDRMAP5[1:0] Input Region mapping, 2.5GB – 3GB
SAMADDRMAP6[1:0] Input Region mapping, 3GB – 3.5GB
SAMADDRMAP7[1:0] Input Region mapping, 3.5GB – 4GB
SAMADDRMAP8[1:0] Input Region mapping, 4GB – 8GB
SAMADDRMAP9[1:0] Input Region mapping, 8GB – 16GB
SAMADDRMAP10[1:0] Input Region mapping, 16GB – 32GB
SAMADDRMAP11[1:0] Input Region mapping, 32GB – 64GB
SAMADDRMAP12[1:0] Input Region mapping, 64GB – 128GB
SAMADDRMAP13[1:0] Input Region mapping, 128GB – 256GB
A Signal Descriptions
A.13 CHI interface signals
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
Appx-A-869
Non-Confidential
