1 Trap Non-secure EL0 and EL1 accesses to PMCR_EL0 to EL2.
This bit resets to 0.
See the Arm
®
Architecture Reference Manual Armv8, for Armv8-A architecture profile for more
information.
HPMN, [4:0]
Hyp Performance Monitor count. Defines the number of Performance Monitors counters that are
accessible from Non-secure EL1 and EL0 modes.
In Non-secure state, HPMN divides the Performance Monitors counters as follows. For counter
n in Non-secure state:
For example, If PMnEVCNTR is performance monitor counter n then, in Non-secure state:
• If n is in the range 0 ≤ n < HPMN, the counter is accessible from EL1 and EL2, and from
EL0 if permitted by PMUSERENR_EL0. PMCR_EL0.E enables the operation of counters in
this range.
• There are six performance counters, specified by PMCR.N.
If n is in the range HPMN ≤ n < 6, the counter is accessible only from EL2.
MDCR_EL2.HPME enables the operation of counters in this range.
If the field is set to 0, then Non-secure EL0 or EL1 has no access to any counters.
If the field is set to a value greater than six, the behavior is the same as if the value is six.
For reads of MDCR_EL2.HPMN by EL2 or higher, if this field is set to 0 or to a value larger
than PMCR_EL0.N, the processor returns the value that was written to MDCR_EL2.HPMN.
This field resets to 0x6.
To access the MDCR_EL2:
MRS <Xt>, MDCR_EL2 ; Read MDCR_EL2 into Xt
MSR MDCR_EL2, <Xt> ; Write Xt to MDCR_EL2
Register access is encoded as follows:
Table B2-74 MDCR_EL2 access encoding
op0 op1 CRn CRm op2
11 100 0001 0001 001
B2 AArch64 system registers
B2.80 Monitor Debug Configuration Register, EL2
100236_0100_00_en Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
B2-502
Non-Confidential
