T
o access the DBGWCR
n
:
MRC p14, 0, <Rt>, c0, cn, 7; Read Debug Watchpoint Control Register
n
MCR p14, 0, <Rt>, c0,
cn, 7; Write Debug Watchpoint Control Register
n
The DBGWCR
n
_EL1 can be accessed through the external debug interface, offset
0x8n8
. The range of
n
for DBGWCRn_EL1 is 0 to 3.
C6 AArch32 debug registers
C6.3 Debug Watchpoint Control Registers
100236_0100_00_en
Copyright © 2015–2017, 2019 Arm Limited or its affiliates. All rights
reserved.
C6-627
Non-Confidential
