2-82 Service Manual
5058-030
200.03 Sensor (registration) late jam (feeding from the tray)
3
Check the sensor (registration)
for proper connection.
Is the above component
properly connected?
Replace the registration/transport
roll assembly.
Go to “Registration/transport
roller assembly removal” on
page 4-143.
Replace the connections.
4
Check the registration/transport
roll assembly.
Is the above component free of
excess wear and
contamination?
Go to step 5. Clean or replace the registration/
transport roll assembly.
Go to “Registration/transport
roller assembly removal” on
page 4-143.
5
POR the machine, and perform a
PRINT test.
Go to “PRINT TESTS” on
page 3-22.
Does the error continue?
Replace the lower engine PCBA.
Go to “Lower engine PCBA
removal” on page 4-98.
Go to step 6.
Problem resolved
6
POR the machine, and perform a
PRINT test.
Go to “PRINT TESTS” on
page 3-22.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-181.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the sensor (registration)
for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch PRINTER SENSOR
TESTS.
4. Touch Sensor (registration).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
3
Check the sensor (registration)
for proper connection.
Is the above component
properly connected?
Replace the registration/transport
roll assembly.
Go to “Registration/transport
roller assembly removal” on
page 4-143.
Replace the connections.
Step Action and questions Yes No
