Lexmark C950 - TTM Tray 4 Media Transport Removal

4-224 Service Manual
5058-030
Go Back
Previous
Next
TTM tray 4 media transport removal
1. Pull the TTM tray 4 media tray from the machine.
2. Remove the two screws (A) securing the TTM tray 4 media transport to the machine.
3. Slide the TTM tray 4 media transport out of the machine and remove it.
