2-108 Service Manual
5058-030
242.03/242.06 Sensor (tray 2 feed out) late jam
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the pick rollers for wear.
Is the above component free of
excess wear and damage?
Go to step 3. Replace the pick rollers.
Go to “Pick roller removal” on
page 4-135.
3
Check the transport rollers for
wear.
Is the above component free of
excess wear and damage?
Go to step 4. Replace the transport rollers.
Go to “Tray module transport
rollers removal” on page 4-213.
4
Check the sensor (tray 2 feed
out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch PRINTER SENSOR
TESTS.
4. Touch Sensor (tray 2 feed
out).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 6. Go to step 5.
5
Check the sensor (tray 2 feed
out) for proper connection.
Is the above component
properly connected?
Clean or replace the sensor (tray
2 feed out). Go to “Sensor (tray
module feedout) removal” on
page 4-200.
Replace the connection.
6
Check the tray module upper
transport motor for proper
operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch 1TM/3TM/TTM upper
transport motor.
Does the above component
operate properly?
Go to step 8. Go to step 7.
To Next Page
