2-120 Service Manual
5058-030
245.03 Sensor (tray 5 feed out) late jam
3
Check the connection between
the lower engine PCBA and the
tray module controller PCBA.
Are the above components
properly connected?
Replace the tray module
controller PCBA.
Go to “HCF controller card
PCBA removal” on page 4-432.
Go to step 4.
Replace the connections.
4
POR the machine, and perform a
print test. Go to
“PRINT TESTS”
on page 3-25.
Does the error continue?
Replace the upper printer engine
PCBA.
Go to “Upper printer engine
PCBA removal” on page 4-189.
Problem resolved
Step Action and questions Yes No
1 Check the media path.
Is the media path free of any
media fragments?
Go to step 2. Remove any media or media
fragments.
2
Check the feed rollers for wear.
Is the above component free of
excess wear and damage?
Go to step 3. Replace the feed rollers.
Go to “HCF feed roll assembly
removal” on page 4-434.
3
Check the transport rollers for
wear.
Is the above component free of
excess wear and damage?
Go to step 4. Replace the transport rollers.
Go to “HCF transport roller kit
removal” on page 4-452.
4
Check the sensor (tray 5 feed
out) for proper connection.
Is the above component
properly connected?
Clean or replace the sensor (tray
5 feed out). Go to “HCF sensor
(tray 5 feedout) removal” on
page 4-446.
Replace the connection.
5
Check the HCF feed/lift motor for
proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch PRINTER MOTOR
TESTS.
4. Touch HCF feed/lift motor
(feed).
5. Touch HCF feed/lift motor
(lift).
Does the above component
operate properly?
Go to step 7. Go to step 6.
Step Action and questions Yes No
