2-160 Service Manual
5058-030
381.27 Sensor (decurler cam HP) lag jam
6
Is the bridge drive motor
properly connected?
Replace the bridge drive motor.
Go to “Bridge drive motor
removal” on page 4-230.
Replace the connection.
7
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the bridge unit interface
card assembly.
Problem resolved
8
Perform a POR.
Does the error continue when
the power is turned off/on?
Replace the finisher PCBA. Go to
“Finisher PCBA removal” on
page 4-281.
Problem resolved
Step Action and questions Yes No
1 Check the sensor (de-curler cam
HP) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch SENSOR TESTS.
3. Touch FINISHER SENSOR
TESTS.
4. Touch Sensor (decurler cam
HP).
Does the display on the
operator panel change every
time the sensing area of the
above sensor is interrupted or
blocked?
Go to step 3. Go to step 2.
2
Is the sensor (decurler cam HP)
properly connected?
Replace the sensor (decurler
cam HP). Go to
“Sensor
(decurler cam HP) removal” on
page 4-245.
Replace the connection.
3
Check the bridge decurler cam
clutch for proper operation.
When performing
motor tests, ensure
that all cover and
door interlock
switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch FINISHER MOTOR
TESTS.
4. Touch Decurler cam clutch.
Does the above component
make an audible clicking
sound?
Go to step 5. Go to step 4.
4
Is the bridge decurler cam
clutch properly connected?
Replace the bridge decurler cam
clutch. Go to
“Decurler clutch
removal” on page 4-237.
Replace the connection.
Step Action and questions Yes No
To Next Page
