Lexmark C950 - Upper Media bin Assembly Removal

4-352 Service Manual
5058-030
Go Back
Previous
Next
4. Remove the four screws securing the top cover (A) to the finisher.
5. Remove the top cover (A).
Upper media bin assembly removal
1. Loosen the two screws securing the upper media bin assembly (A) to the finisher.
2. Lift the upper media bin assembly (A) upward in the direction of the arrow.
A
A
Right
