Lexmark C950 - Right Eject Cover Removal

4-310 Service Manual
5058-030
Go Back
Previous
Next
3. Remove the four screws securing the rear upper cover (B) to the finisher.
4. Remove the rear upper cover (B).
Right eject cover removal
1. Remove the finisher front door assembly. See “Finisher front door assembly removal” on page 4-276.
2. Remove the rear upper cover. See “Rear upper cover removal” on page 4-309.
A
B
Hook
