Lexmark C950 Service Manual

Repair information 4-323
5058-030
Go Back
Previous
Next
5. Remove the two screws securing the bracket (B) to the finisher.
Note: The upper media bin vertical cover (C) has slots that make access to the screws easier, as shown.
6. Remove the bracket (B).
7. Release the hooks securing the sensor (lower media exit) (A) to the bracket.
8. Remove the sensor (lower media exit) (A).
Sensor (media eject clamp HP) removal
1. Remove the rear upper cover. See “Rear upper cover removal” on page 4-309.
2. Remove the upper media bin assembly. See “Upper media bin assembly removal” on page 4-352.
A
B
Front
Clamp
Connector
Right
B
A
Access slots
C
